GA - Series
Robust element & motor
- The GA 15-22’s new compression element is
combined with an IE2 efficiency motor. - GA26-30 with IE3 efficiency motor
- 5-6% higher efficiency compared to belt-driven
systems. - Gear-driven drive train for best-in-class
reliability and limited maintenance.
Advanced monitoring
- The MKS Swipe controller SmartLink
connectivity - Automatic restart after voltage failure.
- Dual pressure set point.
- Delayed Second Stop function.
- Option to upgrade to advanced MKS touch
controller.
High-tech oil vessel
- Protection from oil contamination: very low oil carry-over thanks to the vertical design of the oil vessel.
- Extremely low air losses during load/unload cycle thanks to minimized oil vessel size.
Cooling
- Bigger coolers for lower operating temperature
- Longer oil life
Full Feature (FF)
- Integrated refrigerant air dryer
- Wet vessel ensures lower load on dryer
- Space – saving – Ensures moisture free air
HD Filter
- Superior dust protection
- Fresh air inlet
- Suitable for Indian conditions
Magnetically fixed Pre-filter
- Innovative design
- Dust pre-filtration for Indian conditions
- Improved consumable life
Easy installation
- A true plug-and-play solution for installation companies and OEMs.
- Optional integrated dryer, air filters, and factory-mounted
500L receiver (GA15-22 only)
• Easy transportation by forklift.
• Remarkably compact footprint.
Excellence in quality air
Untreated compressed air contains moisture, aerosols, and dirt particles that can damage your air system and contaminate your end product. The resulting maintenance costs can far exceed air treatment costs. GA compressors provide clean, dry air that improves your system’s reliability, avoiding costly downtime and production delays, and safeguarding the quality of your products.
Integrated Purity
Many Atlas Copco compressors (Full Feature option) come with an integrated dryer that efficiently removes moisture, aerosols, and dirt particles to protect your investment. This quality air expands the life of your equipment, increasing efficiency and ensuring the quality of your final product.
Main benefits of integrated dryer option
The heat exchanger with integrated water separator minimizes the energy required to reach a certain air quality.
• One solution to get the dry compressed air
• Reduced footprints
• Reduced additional investment cost in connecting compressor with dryer.
• Can be outfitted with optional UD+ filters to obtain the exact air quality you need.
| ISO QUALITY CLASS* | DIRT PARTICLE SIZE | WATER PRESSURE DEWPOINT GA** |
WATER PRESSURE DEWPOINT GA*** |
OIL CONCENTRATION | |
|---|---|---|---|---|---|
| Pack unit | 3..4 | 3 microns | - | - | 3 ppm |
| Full Feature unit | 3.4.4 | 3 microns | +5°C / 41°F | +3°C / 37°F | 3 ppm |
| Full Feature unit with Class 2 integrated filter | 2.4.2 | 1 micron | +5°C / 41°F | +3°C / 37°F | 0.1 ppm |
| Full Feature unit with Class 1 integrated filter | 1.4.1 | 0.01 microns | +3°C / 37°F | +3°C / 37°F | 0.01 ppm |
* The table values are maximum limits according to the respective ISO quality class.
** Water pressure dewpoint based on 100% RH at 20°C / 68°F.
*** Specific operating parameters.
